Drilling Fluid Solids Control Equipment Mud Gun 50-60 m3/h
|Place of Origin:||China|
|Model Number:||NJQ Series|
Payment & Shipping Terms:
|Minimum Order Quantity:||1 set|
|Packaging Details:||Export Wooden Case|
|Delivery Time:||15-30 days|
|Payment Terms:||L/C, T/T, Western Union, MoneyGram|
|Supply Ability:||200 sets per month|
|Condition:||New||Product Name:||Drilling Fluid Solids Control Oilfield Equipment Mud Gun For Mud Tank|
|Keywords:||Mud Gun||Application:||Drilling Mud Solid Control|
|Diameter:||2", 3"||Discharge Capacity:||50-60 M3/h|
Solids Control Equipment Mud Gun,
60 m3/h Solids Control Equipment
Drilling Fluid Solids Control Oilfield Equipment Mud Gun For Mud Tank
Mud Gun Descriptions:
Mud Guns are designed for submerged service in mud pits and are popular in 2", 3". Besides, 4” is available against client request. They can be high pressure gun, or low pressure, high volume service such as in mud mixing system employing centrifugal pumps.
All mud guns are equipped with handles and swivel joints as illustrated, permitting 360° rotation. Length should, in all instances, be specified when ordering.
Mud guns are usually used along with agitator. That means, almost every compartment on tank will request a mud gun. And there are bottom type mud gun, pivot type mud gun, and non spin type mud gun. For mud gun nozzle, there are 1 or 3 as options.
Features of Mud Gun
1.High quality national standard steel.
2.Discharge nozzles can be polyurethane and tungsten carbide alloy material.
3.Flexible on configuration of size and pressure rates.
4.Simple design and easy to operate.
5.High quality painting job per international standard.
Technical Parameters of API Oilfield Solid Control Drilling Mud Gun
|60 m3/h||60 m3/h||50 m3/h||50 m3/h|
|Nominal diameter||80 mm||80 mm||50 mm||50 mm|
|Working pressure||≤1 MPa||≤6.4 MPa||≤1 MPa||≤6.4 MPa|
According to the mud tank depth
Complete soilds control system we supply:
A complete solid control system,including Shale Shaker, Mud Cleaner ,Desander ,Desilter, Centrifuge, Cutting Dryer ,Agitator, Mixing Hopper, Flare Igniter, Various Tanks, Pumps, Degassers etc .
Dongying OilMan Machinery Equipment Co.,Ltd is a professional supplier of various petroleum equipment, including drilling rig accessories, well control system, drill string, handling tools, downhole tools, OCTG, drilling tools, cementing tools and spare parts with API certification. Our products have been exported to Russia, America, Middle East, South America, Southeast Asia, Central Asia, African, Australia, Europe etc. Our company is willing to cooperate and make common progress with friends at home and abroad with first-class products, first-class service and reasonable prices.
API-5CT, API-10D, API-7K, API-11E, API-6A, API-11AX, API-5D, ISO 9001, ISO14001, ISO18001 etc.
