Factory Price API 8C Oil Field Well Drilling Equipment Drilling Rig Traveling Block and Hook
Travelling Blocks
Traveling block & hook is one of the lifting equipments for petroleum drilling rig and workover rig with the integral design, which can shorten the length between traveling block and hook, perfectly meeting the traveling space for lifting system.
The travelling blocks conform to API Spec. 8A/8C.
| Model | YC225 | YC315 | YCF315 | YC450 | YC585 | YC675 |
| Max. hook load kN | 2250 | 3150 | 3150 | 4500 | 5850 | 6750 |
| O.D. of sheaves mm (in) | 1120 (44) | 1120 (44) | 1270 (50) | 1524 (60) | 1524 (60) | 1524(60) |
| Number of sheaves | 5 | 6 | 6 | 6 | 7 | 7 |
| Dia. of wire line mm(in) | 29 (11/8) 32 (11/4) | 32 (11/4) 35 (13/8) | 35 (13/8) | 35 (13/8) 38 (11/8) | 42 (15/8) | 45 (13/4) 42 (15/8) |
| Overall dimension (LxWxH) mm | 2294x1190x630 | 2680x1350x974 | 2145x1380x1635 | 3075x1600x800 | 3086x1600x953 | 3087x1600x970 |
Recommend Products
Drilling Hooks
The body, the bail, and the bail support are cast with special alloy steel.
Equipped with a hydraulic snubber assembly toprotect drill pipe joints when making up/breaking out connections.
At the hook there is a reliable safety device.
The primary-load-carrying parts of hook are subject to NDE test.
It is provided with a braking device to lock up & lock out the body.
The hooks conform to API Spec. 8A / 8C.
| Model | DG225 | DG315 | DG450 | DG675 |
| Max. hook load kN | 2250 | 3150 | 4500 | 6750 |
| Major-hook opening mm (in) | 190 (7 1/2) | 220 (8 5/8) | 220 (8 5/8) | 240 (9 7/16) |
| Diameter of Major-hook mm (in) | 160 (6 1/4) | 180 (7) | 180 (7) | 228 (9) |
| Spring travel mm (in) | 180 (7) | 200 (8) | 200 (8) | 220 (8 7/10) |
| Overall dimension (LxWxH) mm | 2545x720x750 | 2953x890x880 | 2950x890x880 | 3600x1110x1020 |
Hook Block Assembly
Joining the travelling block and the hook together reduces overall length to satisfy the requirements of a top drive.
The shafts of travelling block are forged with alloy steel provided with a lubrication hole of bearing for one sheave.
The grooves of sheave are intermediate frequency quenched so as to improve the surface hardness and prolong the service life.
The sheaves are equipped with double-row conic roller bearings. Each bearing has its own lubrication channel. The hook block assembly conforms to API Spec. 8A /8C.
There is a reliable safety device at the hook. The primary-load-carrying parts of hook are subject to NDE test.
| Model | YG60 | YG70 | YG80 | YG90 | YG110 | YG135 | YG160 | YG180 | YG225 |
| Max load (kN) | 585 | 675 | 800 | 900 | 1125 | 1350 | 1580 | 1800 | 2250 |
| Pulley OD (mm) | 610 | 610 | 610 | 760 | 760 | 760 | 760, 915 | 915 | 915 |
| Pulley Qty | 4 | 3 | 3 | 3 | 4 | 4 | 4, 5 | 4 | 5, 6 |
| Wireline dia. (mm) | 22 | 22 | 26 | 26 | 26 | 26 | 26, 29 | 32 | 29, 32 |
| Hook type | Three | ||||||||
| Hook open hole size (mm) | 110 | 110 | 110 | 110 | 150 | 152 | 180 | 190 | 190 |
| Model | YG170 | YG315 | YG450 |
| Max. hook load kN | 1700 | 3150 | 4500 |
| O.D.of sheaves mm (in) | 915 (36) | 1270 (50) | 1524 (60) |
| Number of sheaves | 5 | 6 | 6 |
| Dia. of wire line mm (in) | 29 (11/8) / 32 (11/4) | 32 (13/8) / 35 (13/8) | 35 (13/8) / 38 (11/2) |
| Major-hook opening mm (in) | 180 (7) | 220 (85/8) | 220 (85/8) |
| Major-hook dia mm (in) | 150 (6) | 180 (7) | 180 (7) |
| Minor-hook dia mm (in) | 90 (31/2) | 120 (43/4) | 120 (43/4) |
| Overall dimension (LxWxH) mm | 3294x960x630 | 4322x1350x784 | 4887x1600x880 |
