Drilling Rig Use Wellhead Tool Type SJ Single Joint Elevators Auxiliary Elevators
Product Details:
| Place of Origin: | China |
| Brand Name: | OilMan |
| Certification: | API 8A/8C |
| Model Number: | SJ, SP, SJX Types |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 piece |
|---|---|
| Price: | USD150-800/piece |
| Packaging Details: | Export Wooden Case |
| Delivery Time: | 15-30 work days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 300 pieces per month |
|
Detail Information |
|||
| Condition: | New | Product Name: | Drilling Rig Use Wellhead Tool Type SJ Single Joint Elevators Auxiliary Elevators |
|---|---|---|---|
| Keywords: | Single Joint Elevator/Auxiliary Elevator | Application: | Oil Drilling |
| Warranty: | One Year | Material: | Alloy Steel |
| Processing Type: | Forging | Color: | Red Or As Customer Requirement |
Product Description
Drilling Rig Use Wellhead Tool Type SJ Single Joint Elevators Auxiliary Elevators
Drilling Rig Use Wellhead Tool Type SJ Single Joint Elevators Auxiliary Elevators
Description
Type SJ, type SP and type SJX single joint elevators are designed and manufactured in accordance with API Spec 8A/8C specification for drilling and production hoisting equipment. They have a complete range of sizes. They are widely used in drilling, servicing and cementing for oil and gas well.
Type SJ single joint elevators are the requisite hoisting tools for catching single pipe up and down.
Type SP single joint elevators are the requisite hoisting tools for catching pipe with degree up and down.
Type SJX single joint elevators are hoisting tools for single pipes or working together with the professional tools CRT to move the tubulars from gate to well center.
Applications:
Oil drilling,drilling rig parts,drilling equipment,wellhead Servicing
Features:
1.reasonable price
2.quality assurance
3.factory direct
4.adequate stocks, fast delivery
| Model | Size | Max.Load | |
| in | kN | Short Tons | |
| SJ | SJ | 45 | 5 |
| 3.1/2-4.3/4 | |||
| 5-5.3/4 | |||
| 6-7.3/4 | |||
| 8.5/8-10.3/4 | |||
| 11.3/4-13.3/8 | |||
| 13.5/8-14 | |||
| 16-20 | |||
| 21.1/2-24.1/2 | 60 | 6 | |
| 26-28 | |||
| 30-36 | |||
| Model | Size | ||
| in | kN | Short Tons | |
| SP5° | 2.3/8-10.3/4 | 45 | 5 |
| SP12° | 2.3/8-4.1/2 | ||
| SP18° | 2.7/8-6.5/8 | ||
| Model | Size | ||
| in | kN | Short Tons | |
| SJX | 2.3/8-4.1/2 | 60 | 5 |
| SJX | 4.1/2-7 | ||
| SJX | 7-10 | ||
| SJX | 10-14 | ||
| Size | Rated Cap.(kN) | |
| in | mm | |
| 23/8-27/8 | 60.3-73.03 | 45 |
| 31/2-43/4 | 88.9-120.7 | |
| 5-53/4 | 127-146.1 | |
| 6-73/4 | 152.4-193.7 | |
| 85/8-103/4 | 219.1-273.1 | |
| 113/4-133/8 | 298.5-339.7 | |
| 135/8-14 | 346.1-355.6 | |
| 16-20 | 406.4-508.0 | |
| 211/2-241/2 | 546.1-622.3 | 60 |
| 26-28 | 660.4-711.2 | |
| 30-36 | 762.0-914.4 | |
